领域与介绍/Brief introduction：

滤油机是在入选和吸收的作用国内外较为先进新技术的基础性上，尽我所能工司自行研发培训的一件行业针对于西林瓶的灌装设备、上塞、旋（轧）盖机。滤油机采取美国全进出口高定位高精准度全开放式式凸轮机构测量范围工装夹具器，定位高精准性好，操作稳定，操作生命长。该测量范围器成分单纯，长期性的操作免修理。远程服务器常见适用人群于多种多样小用量液态的分装、压塞及旋（轧）盖，如按摩油、接种剂等。很广用以美食、医药化工厂、化工厂市场及科研开发科技领域。设配既可单机手游产出，又可与洗瓶机、干躁机等设配组成的联调产出线。根本具备地区GMP追求。远程服务器也可以按照客服追求加剧电力工程标准配置。NFGX-5/50 Automatic Vial Filling&rotation (rolling) machine is built in the absorption of foreign advanced tecnology, based on independently developed by the company ,It is the domestic leading level.This machine is suitable for a variety of small doses of liquid filling&capping such as oil, injection . Widely used in food, pharmaceutical, chemical industries and scientific research.  Single machine can produce, but also with washing machine, dryer and other equipment linked production line. Full compliance with the GMP requirements. The machine according to customer requirements to upgrade the electrical configuration

显著特点/Characteristic:：

◆人与机器工具栏添加、操作的举例子简单方便、PLC控住，装量*。Human-machine interface settings, an easy and intuitive, PLC control, the amount of precision equipment. ◆直流变频空调掌控、产出高速度多种调准、定时计数法。Frequency control, the production rate be adjusted automatically count  ◆手动停电功能表，无瓶不装罐。No bottle no filling.◆圆球定位系统式灌装设备，安全能信。Disc positioning filling, stable and reliable.◆高计算精度轴承测量范围计把控好，手机定位*。High-precision cam meter control, precise positioning.◆利用SUS304及316L304不绣钢制作，截然契合GMP需求。SUS304 and 316L stainless steel, full compliance with GMP requirements.

技术工艺主要参数/ technical parameters：

装量的范围Filling volume	5-50ml
装量出现偏差的原因loading error	≤ ±1%
旋（轧）盖通过率率 Rotation (rolling) Cover pass rate:	≥99%
生育业务能力Production capacity	30-60瓶/分 钟  中速 70-100瓶/分 钟 🐠;&nꦿbsp;   高速的 30-60 bottles / min&n﷽bsp; 70-100 bottles / minute (high speed)
压塞率Tamponade rate	≥99%
外接电源 Power	380V/50Hz
最大功率Power	2.0 kw
机设备总重量Net weight	600 kg
外型尺寸规格 Dimension	2000*1000*1500mm
