的主要用途与简绍/Brief Introduction：

这个机器是所代替内服方式液有机金属瓶的新设备，切底处理了已往内服方式液有机金属瓶的欠佳目的。该种灌封机所用到的的金属瓶，不断不想要洗瓶机、烘干功能机，更不想要空气消毒，能够间接灌封。这个机器全主动理瓶、进瓶、装罐，装罐量稳固，无漏滴，无瓶不装罐。上盖、密封率多达100%。此机技艺现进，空间小、运动稳固、燥声低，操作步骤维修费、的清洗简便等特征，可以适合GMP标。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本尺寸有低挡和公路不同出现供您选购。Note: this model has two kinds of low speed and high-speed production for your choice.

特征 Characteristic

◆远程服务器适于于繁多易折瓶口服药液收费装罐和封膜。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆几乎所有电热器部件均运用知名度该品牌。All electrical components adopt famous brand◆该机运作更直观有利，无瓶不装罐，压力容器检验*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折泡沫塑胶瓶灌封机的其主要型式与的工作原理Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型原浆、油类液易折金属瓶灌封机包括理瓶器、理盖器、主转动平台、关联带摩擦送小瓶安装设备、空罐检漏安装设备、灌装生产线设备、排除安装设备、热熔胶封设备、自动机械厂小指夹瓶设备、交流伺服调速电机调速电机摩擦上瓶设备与出瓶设备等组成了。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆丝机采用的服用液易折可塑料饮料瓶、盖就是定干净干燥区分娩的，可以有泡脚药材同意证，于是瓶身与底盖经表达和"去委托"后可一直开始灌封间。凭借理盖器、理瓶器的手动定项归整，筛除交叉底盖及瓶身底口朝下的瓶，使定项后的包材喂料有标准地开始气流输送 轨道组件中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定向分配后服用液易折塑胶片瓶在运输道路第二排Directional oral liquid after folding plastic bottles in conveying rail out easily

高技术性能technical parameters：

型号model	NLGFY-40	NLGFY-80
装量面积The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
塑封率Hot sealing intensity	》99%
装量计算误差The load error	《1.5%
受伤率damage rate	《1.0%
公率power	2KW	3KW
电原Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
含量 Weight	700Kg	800Kg
