的主要用途是什么与概况/Brief Introduction：

本种植线由全定时理瓶机、全定时变頻式多头数片（粒）机、定时变頻式塞纸旋盖机、电滋感应器铝铂粘口机、柜式标贴飞机机组成。适应用在于药厂、饮食、日化用品等互联网行业的糖衣片、丸剂、冲剂和其他导形片的记数罐装、塞纸、旋盖、粘口、标贴等包裝全环节。The production line consists of auto bottle unscrambler, automatic frequency variable counting machine, automatic frequency variable paper inserting & capping machine, electromagnetic induction aluminum foil sealing machine and vertical labeling machine. It is suitable for counting, filling, paper inserting, cap screwing, sealing and labeling whole packing process of troche, capsule, granule or other abnormal bottles in pharmacy, foodstuff and cosmetics and other field.

性能/Characteristic：

◆自动的理瓶机，理瓶操作过程全都使用机械设备姿势，免亲自照看，省时杠杆原理。Automatic bottleunscramble bottle unscrambled completely by mechanism, need not additional caretaker, save time and labor.◆直流变频空调式筛动式数片机：嗡嗡声小、落片平稳、计数器合理、快与慢快与慢能够直流变频空调式也可以调接，并装没有瓶停下落片的光控装制.Counting machine: Low noise, counting accurate, speed adjusted by frequent inverter, no bottle no filling.◆交流变频器式塞纸旋盖机：制定方法先进的，空间结构有效率紧密，一键送纸、眉刀断开 ，加速度声音速度进行交流变频器变频调速，无瓶一键关机。Paper inserting & capping machine: Advanced .principle, reasonable structure, automatic paper feed and cut, speed adjusted by frequency inverter, no bottle automatic stop sytem.◆铝铂纸粘口机：可配无铝铂纸自动的删去平衡装置，速率在必定的范围内能调Aluminum foil sealing machine: Automatically eliminate function for cap that has no aluminum foil, Speed can be adjusted in certain scope.◆可移胶标贴纸机：具备有无瓶时全电脑自动停下出标，全电脑自动打批号工作。 Labeling machine: no bottle no label feeding, automatic code typing.

水平数据/ Technical Parameters：

适宜外形尺寸Bottle Range	15-500ml
生产方式效果 Productivity	30-60瓶/分 30-60bottles/min
主机电源Power Supply	380V/50Hz
效率 Total Power	4.5 kw
生產线总长Dimension	8000*900*1700mm
