应用场景与概述/Purpose and introduction：

NQGF型西林瓶粉针洗烘预包装轧盖标贴一体化线 由QCL题材柜式高周波波洗瓶机、AQMR队道式暧风无限循环法过滤除菌真空烘箱、NQFGX题材精机螺旋轴粉剂预包装机、NQ-50轧盖机、NQWTB-120标贴发电机组成，也可单人安全使用。适当于7-25ml样式的西林瓶粉针的产生。能来完成喷淋系统加水、高周波波粗洗、瓶壁上水洗器、瓶壁内累计两次无限循环法水洗器、一回吹气、一回优质水洗器、累计两次吹气、瓶壁上吹气、清洁工作、提前预热、烘干机过滤除菌去热原、水冷却、预包装、加塞、轧盖、标贴等二十几个道多种工序。NLGF schering bottles booster injection wash baked repackaging rolling cover labeling line consists of QCL series vertical ultrasonic bottle washer, ASMR tunnel type hot air circulation oven. NFFGX series CNC screw powder filling machine, NF-50 rolling machine, NFWTB-120 labeling machine, and also can be used stand-alone. Suitable for 7 to 25 ml specification schering bottles of water production. Can finish the spray water injection, ultrasonic thick bottle washing, the outer wall of water flushing, bottle wall continuous secondary circulating water flushing, a blowing, a fresh water rinse, two consecutive bottle blowing, blowing the outer wall, preheating and drying sterilization to pyrogen, cooling, packaging, gasser, cover, labeling and so on more than 20 procedures.

显著特点/characteristic：

◆洗瓶机主要包括机械化手夹瓶，用于不同尺寸的西林瓶；Bottle washer adopts manipulator clamp bottle, is suitable for a variety of specifications of schering bottles;◆洗瓶适用热气喷针导杆跟踪目标导入表格习惯，洁净效用好，节电资源。并均有针架防发抖部件，提升喷针导入表格可乐瓶的精准度，提高断针物理现象情况；Reciprocating mixer washing bottle with water spray needle track insert way, cleaning effect is good, save energy. And is equipped with needle shake device, improve the accuracy of injection needle inserted into the bottle, reduce breakage phenomenon;◆洗瓶整体的水雾管道阀门、喷针非常孤立拆开，尽量避免了重叠的污染，完全符合GMP实验室管理标准标准要求；Mixer washing bottle the water pipe, injection needles completely separate, to avoid the cross contamination, in line with the GMP requirements;◆洗瓶机进瓶螺栓前改装保護块，有保護螺栓，避免碎瓶使用；Pieces into the bottle inside the screw before adding buffer block, protect the screw, reduce broken bottle;◆洗瓶机出瓶利用综合進口关联带，连到拨瓶块传送西林瓶，加载不稳能信；Pieces out of the bottle inside the whole import synchronous belt, the connection dial the bottle conveying schering bottles, operation is stable and reliable;◆恒温干燥箱用暖风反复加熱，水温不匀，高效；Oven adopts hot air circulation heating, temperature uniformity, energy saving;◆真空烘箱安装有防时不时跳闸防护效果。运营安全管理；Mixer oven has suddenly loses power protection function. Run security;◆烤箱可配循环系统水冷式系统设计，不消耗房屋新风量，减轻房屋的压力不均衡性的危险加温疗效好；Mixer oven can match circulating water cooling device, not loss room air volume, reduce the risk of differential pressure imbalance in room cooling effect is good.◆烤箱可配风气体压力电脑自动均衡性控制系统限制小房间和烤箱的风气体压力不均衡性从而造成的工作温度高段摆动，装灌间洗烘间工作温度升高效一些表的话题；Mixer automatic oven can match differential pressure balance control system to reduce the room and high temperature oven pressure difference caused by the imbalance of period of migration, filling between wash between baking temperature and so on a series of problems;◆烘干箱拥有DOP加测工具接口方式(涵盖静压、风压、玦尘水粒子加测工具口)；Mixer oven with DOP test interface (including wind pressure, wind speed, dust particle detection);◆烘干箱闭式冷却塔段可带迅雷在线高压蒸汽灭菌特点(FDA特选)；Mixer oven cooling segment with the function of sterilization (FDA selected);◆恒温干燥箱网带可带高周波遍布CIP网络刷洗操作系统；Type mixer oven mesh belt with ultrasound scanning CIP online cleaning system;◆烘烤箱内腔室可做出全方向位置、多斜度低压水清洗；In pieces inside the oven chamber can be all-round, multi-angle high-pressure water flushing;◆散装机进行国际上更高端的设定管理理念，极具稳定度，有时分瓶精确性，更新年纪件不方便；Mixer racking machine adopts the most advanced design concept, high speed, and bottles of accurate, replacement of a convenient;◆分开装袋机运用交谈交流伺服无刷电机无刷电机控制器包分开装袋挤出机螺杆飞速转动，装量准确度；Mixer racking machine adopts ac servo motor drive the repackaging screw rotation, the load accurately;◆预包装机主要采用装量的修改马上在触碰屏上改变；Mixer packer adopts the load adjustment directly on a touch screen;◆灌装机可选择配百级重复式层流罩；Mixer packer optional circulating laminar flow hood best level;◆预包装机无瓶终止预包装，无瓶没加塞功用。Racking machine without stop packing bottle, no bottle no stoppered function.◆整线通过PLC总管理、调频器、触控屏管理技能，作业安稳信得过。触控屏可表明各单机游戏的作业工作的情形，各管理点的通水压力、汽压、压力、温等表明，各触点开关工作的情形和洛天依表明，洛天依个人能力检测和洛天依剖析及排除故障措施。使这个出产工作以达到定时化管理，联线兼有自我控制平衡点装备，确定出产平衡信得过。The whole line adopts PLC control, inverter, touch screen control technology, stable and reliable running. Touch screen can display the running state of each units, each control point of the water pressure, air pressure, air pressure, temperature, etc, according to the switch state and fault display, fault self-diagnosis and fault analysis and elimination method. Make the whole production process automation control, on-line has the automatic balancing device, ensure production equilibrium is reliable.通过朋友的要求，还可供配搭：According to the needs of customers, but also available for selection:◆simens、斯耐德、三菱PLC、台达等项目控制程序；Pieces of Siemens, schneider, mitsubishi, Taiwan brands such as control system;◆水、气工作压力、温度及超声心动图波抗拉强度、尘沙激光束、空气流速线下验测、提醒、记录查询、彩印平台；Pieces of water, gas pressure, water temperature and the intensity of ultrasonic, dust particles, wind speed on-line detection, alarm, record and print system;◆ORABS、CRABS、灭菌防护器设备。ORABS, CRABS, aseptic isolator system.

枝术因素：/technical parameters

规格型号 model

的生产销量力production capacity

洗瓶通过率率Washing bottle percent of pass

洗瓶划伤率Washing bottle breakage

灭菌方法温湿度sterilizing temperature

灌装随机误差The repackaging of error

加塞达标率率Gasser percent of pass

暖空气层流洁钻石净度度Laminar air cleanliness

正空抽速Vacuum pumping speed

电感量 capacitance

电源模块power supply

总剩余电量Total transmission energy

外观简约时尚长宽高boundary dimension

7-25ML新国标西林瓶 7-25ML GBvial

300瓶pcs/分min ～600瓶pcs/分min

≥99%

≤0.1%

300℃-350℃

≤±3%(0.1-10h)

≥99%

100级100c

25m3/H(外配)100cbm/H ～50m3/H(外配)100cbm/H

96kw～235.5kw

380v,50HZ

约 8200KG

约 2000×1750×2370mm
